| 1 |
Model |
ELX-10 DM SE |
| 2 |
Capacity in full Height |
1000kgs |
| 3 |
Fork Size (L x W) |
1150 x 550mm |
| 4 |
Minimum Height |
90mm |
| 5 |
Max. Lift Height-H |
2500mm |
| 6 |
Mast Height Lowered-H1 |
1850mm |
| 7 |
Mast Height Extended-H2 |
3000mm |
| 8 |
Battery |
12v x 60Ah |
| 9 |
Out board Battery charger |
12v / 35 Amps |
| 10 |
Hydraulic pump Motor |
12v / 1KW |
| 11 |
Make (Hydraulic pump Motor) |
Dowty |
| 12 |
Lifting Speed Without Load |
0.08m/sec |
| 13 |
Lifting Speed With Load |
0.06m/sec |
| 14 |
Lowering Speed Without Load |
0.12m/sec |
| 15 |
Lowering Speed With Load |
0.10m/sec |
| 16 |
Travel Speed Unladen |
Manual |
| 17 |
Travel Speed laden |
Manual |
| 18 |
WHEEL ( 2 Nylon Support Wheels) |
Dia 180 x 50mm |
| 19 |
WHEEL ( 4 Nylon Load Wheels) |
Dia 82 x 70mm |
| 20 |
Turning Radius |
1385mm |
