| 1 | Capacity | As per Customer Requirement |
| 2 | Lift Height-Hook ht | 6mtr |
| 3 | Travel Length | Any length |
| 4 | Lifting speed | 6mtrs/min |
| 5 | Linear speed | 12mpm |
| 6 | Hoist Details | Electric Wire Rope or Chain Hoist |
| 7 | Construction | ISMB 250 and ISMB 150 beams, plates of 250*250*12thk with all necessary gussets, fasteners Acrylic sheet shall be provided for the extension. |
| 8 | Input Power | 3 Phase AC Input Power |
| 9 | Electricals | C rail system / DSL |
| 10 | Civil | Civil work is not in our scope. Civil columns not in our scope. |
| 11 | Finish | Golden yellow paint for the monorail |
