| 1 | Capacity | 500kgs |
| 2 | Height-H | 1500mm |
| 3 | Arm Length | 2000mm |
| 4 | Rotation | 270° with Manual rotation |
| 5 | Hoist Details | 500kgs Electric Wire Rope Hoist of 3mtr lift height |
| 6 | Construction | Jib crane is fabricated with seamless tube of 180 - 220mm OD and ISMB 200 housing for the arm and finished with golden yellow paint. |
| 7 | Input Power | 3 Phase AC Input Power |
| 8 | Electricals | Festoon cables are provided for the arm travel with overload limit switches for the safety. Up and down, & cross limit switches are provided for extreme ends. |
| 9 | Emergency Switches | Is provided at bottom of the pillar. All electrical items are of standard make. |
| 10 | Civil | Civil work is not in our scope. However pit dwg shall be provided. |
